GENERATOR

• Rated frequency : 220~380V/50Hz
• Rated output (KVA): 10
• Max. output (KVA): 10.6
• DC output: 12V,8.3A
• Phase NO.: 3-Phase
• Excitation mode: Self-excitation,brush
• Power factor (Cos ):0.8
• Insulation grade: H
• Fuel tank capacity (L): 26
• Starting system: Electric start
• Engine type: 1-Cylinder ,4-Stroke, Air-cooled,Veritical
• Cylinder No-borexstroke (mm): 1-100x85
• Displacement (ml): 667
• Compression Ratio: 20:1
• Rated rotation speed (r/min): 3000
• Rated power [KW]:9.5

• Lube capacity (L):2
