WELDING MACHINE

• Rated frequency : 220V/50Hz
• Rated output (KVA) : 2.0
• Welding Voltage Without Load (V) : 50~60
• Rated Current (A) : 200
• Work Voltage (V) : 25~30
• Current Regulation Range (A) : 70~220
• Welding Load Continuous Ration : 60%
• Phase NO. : 1-phase
• Excitation mode : Self-excitation,brush
• Power factor (Cos ) : 1
• Insulation grade : F
• Fuel tank : capacity (L) 12.5
• Starting system : Electric start
• Engine type : 1-Cylinder ,4-Stroke, Air-cooled,Veritical
• Cylinder No-borexstroke (mm)1-92x75
• Displacement (ml) : 499
• Compression Ratio : 19.5:1
• Rated rotation speed (r/min) : 3000
• Rated power [KW] : 7.6
• Lube capacity (L) : 1.65
• Fuel type : 0#(summer), -10#(winter), diesel oil
• Lube type : SAE 10W-30(CD grade or above)
• Panel type : General panel

• Fuel consumption (g/kw.h) : 275
